33 KV Bay from 220/33 KV Substation with 2.7 KM 33 KV Express Feeder.
-
33 KV Switch yard with 1+2 Panel of 33 KV 1200 Amp Breaker, 33 KV Metering Cubical, 33 KV Protections CT’s & PT’s.
-
3 x 2500 KVA, 33/0.433 KVA Transformers with OLTC.
-
1 + 3 Nos 33 KV 800 Amp I/D Breakers Panel.
-
Main LT PCC with 2 Nos of LT Bus Couplers.
-
APFC Capacitor Panel with 3000 KVAR Capacitors.
-
300 sq mm, 33 KV XLPE Cable 500 Mtrs.
-
May Duct, Malaysia make LT Compact Bus Trunking System with 3200 Amp, 2500 Amp, 1600 Amp, 400 & 300 Amps Bus bar system totaling length of 980 Mtrs from Main LT PCC to various machineries in Mill area with Tap Up Box with MCCB of various rating. First time introduced in India.
-
LT Cables of all sizes @ 8000 Mtrs.
-
Street Lights 65 Nos.
-
Plant Lighting with 2200 Nos of Double Tube Light .Fittings.
